Đầu ghi hình 8 kênh HCVR4108-HS-S2
Đầu ghi hình 8 kênh HCVR4108-HS-S2
Đầu ghi hình 8 kênh HCVR4108-HS-S2
Nhà sản xuất: Dahua
Mã sản phẩm: DAUGHI-HCVR4108-HS-S2
Tình trạng: Còn hàng
4.300.000đ

Đầu ghi hình 8 kênhHCVR4108-HS-S2 * Sản phẩm được phân phối tại Nghĩa Hưng - Nam Định. Lắp đặt vận chuyển tận nơi. Gọi điện trực tiếp để tư vấn thêm. ĐT: 0984886188 - 0912537003

Ghi hình All ch 720 với khung hình 1~25fps,
Phát lại Đồng thời tất cả các kênh 720P
Video  4/8 BNC input; output: 1HDMI, 1 VGA
Audio 1 kênh vào 1 kênh ra hỗ trợ đàm thoại 2 chiều
Báo động N/A
Phân giải 1920×1080, 1280×1024, 1280×720, 1024×768
Ngoại vi 1 SATA HDD(4TB), 2 USB, RJ-45 port (10/100M)
Khác DC12V/2A, 10W, 0.5KG,205mm×205mm×40mm
Tribrid Kết nối đồng thời 4/816 kênh CVI hoạc 4/816 kênh analog, hỗ trợ 2 camera IP


>Support HDCVI/Analog/IP Video input
>H.264 dual-stream video compression
>HCVR4104/4108/4116HS-S2: All channel 720P recording
>HDMI/VGA simultaneous video output
>4/8/16 channel synchronous playback, GRID interface & smart search
>Support Multi-brand network cameras: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videosec, Vivotek and etc.
>ONVIF Version 2.4 conformance
>Support 1 SATA HDD up to 4TB, 2 USB2.0
>3D intelligent positioning with Dahua PTZ dome camera
>Multiple network monitoring: Web viewer, CMS(DSS/Smart PSS)&Smart Phone(DMSS)

ModelDH-HCVR4104HS-S2DH-HCVR4108HS-S2DH-HCVR4116HS-S2
System
Main ProcessorEmbedded processor
Operating SystemEmbedded LINUX
Video
Input4 channel, BNC8 channel, BNC16 channel, BNC
  StandardAnalogNTSC/PAL
HDCVI720P HDCVI Camera
IPSupport 2ch 1080P/720P IP Camera
Audio
Input1 channel, RCA
Output1 channel, RCA
Two-way TalkReuse audio input/output channel 1
Display
Interface1 HDMI, 1 VGA
Resolution1920×1080, 1280×1024, 1280×720, 1024×768
Display Split1/41/4/8/91/4/8/9/16
Privacy Masking4 rectangular zones (each camera)
OSDCamera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
Video/Audio CompressionH.264/G.711
Record RateMain Stream:720P/960H/D1/(1~25/30fps)1*720P(1~25/30fps)+7*(1~15fps)/960H/D1 (1~25/30fps)1*720P(1~25/30fps)+15*(1~15fps)/960H/D1 (1~25/30fps)
Bit Rate96~4096Kb/s
Record ModeManual, Schedule(Regular(Continuous), MD), Stop
Record Interval1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection
Trigger EventsRecording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer & Screen tips
Video DetectionMotion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
Playback & Backup
Sync Playback1/41/4/91/4/9/16
Search ModeTime/Date, MD & Exact search (accurate to second)
Playback FunctionsPlay, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
Backup ModeUSB Device/Internal SATA burner/Network
Network
EthernetRJ-45 port (10/100M)
Network FunctionsHTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, SNMP, P2P
Max. User Access128 users
Smart PhoneiPhone, iPad, Android, Windows Phone
Storage
Internal HDD1 SATA port, up to 4TB
Auxiliary Interface
USB Interface2 ports(1 Rear), USB2.0
RS4851 port, For PTZ Control
General
Power SupplyDC12V/1.5ADC12V/2A
Power Consumption10W(without HDD)
Working Environment-10°C ~+55°C / 10%~90%RH / 86~106kpa
Dimension(W×D×H)Compact 1U, 260mm×220mm×40mm
Weight0.75KG(without HDD)


Tag: Đầu ghi hình, 8 kênh, HCVR4108-HS-S2
